Summary of Contents for Boge FOCUS
- Page 1 Operating instructions FOCUS compressor control for screw compressors...
- Page 2 Phone: ++49 / 52 06 / 6 01- 0 Fax: ++49 / 52 06 / 6 01-200 Mail: info@boge.com Net: www.boge.com As of: 08 / 2009 No. 596.0898.18 Nominal price: 5,00 BOGE FOCUS compressor control for screw compressors Page I Inhalt.pm6.5 - USA...
- Page 3 Table of contents Page II BOGE FOCUS compressor control for screw compressors Inhalt.pm6.5 - USA...
-
Page 4: Table Of Contents
Power failure cycle protection ............1.18 Motor spinning time ..............1.18 Star phase time control ..............1.18 Pressure range selection .............. 1.18 Parameterization of frequency converter ........1.19 TAN test ..................1.19 BOGE FOCUS compressor control for screw compressors Page III Inhalt.pm6.5 - USA... - Page 5 Basic module ................1.22 Analogue output module .............. 1.23 RS 485 module ................1.23 Fault messages ................1.24 List of fault messages ..............1.24 1.10 Parameter overview ..............1.26 Page IV BOGE FOCUS compressor control for screw compressors Inhalt.pm6.5 - USA...
-
Page 6: The Boge Control Concept
An interruption of the power supply is effected by means of the mains dis- connector of the compressor. Modules The basic equipment of the FOCUS consists of a basic module and a key- pad/display unit (TAN). Amongst others the following modules are optionally available: –... - Page 7 Lit: Compressor is switched on. Emergency-Stop pushbutton The Emergency-Stop pushbutton interrupts the power supply for the contac- tor coil. The control is still energized and generates a corresponding display. Page 1.2 BOGE FOCUS compressor control for screw compressors FOCUS.pm6.5 - USA...
-
Page 8: Operation
If the compressor status Ready is displayed, the compressor is in the "ready-for-operation" status. That means that the compressor automatically (re)starts pressure and/or time controlled – as long as the conditions to do so are fulfilled. BOGE FOCUS compressor control for screw compressors Page 1.3 FOCUS.pm6.5 - USA... -
Page 9: Run-Up Phase
The display of the TAN has to be cleaned with a damped yet not wet cloth from time to time. As detergents customary household detergents for greasy surfaces can be used. No further maintenance is required for the control. Page 1.4 BOGE FOCUS compressor control for screw compressors FOCUS.pm6.5 - USA... - Page 10 The display then moves to the left with decreasing temperatures (into the direction LO). If the arrow key is pressed, the compressor status is displayed again. Pressing of the arrow keys leads to the next display. BOGE FOCUS compressor control for screw compressors Page 1.5 FOCUS.pm6.5 - USA...
-
Page 11: Display Information
Load cycles of Counts the effected load cycles of the internal combi- internal receiver nation receiver. (One cycle consists of 1 x output and 1 x no output each) Page 1.6 BOGE FOCUS compressor control for screw compressors FOCUS.pm6.5 - USA... -
Page 12: Info # 1
BLS, is dis- played. If only the timer is active (cyclic changing time set to 0) no time is dis- played. BOGE FOCUS compressor control for screw compressors Page 1.7 FOCUS.pm6.5 - USA... -
Page 13: Date / Time
RS485 module: – 30, analogue output module: – 4X. If the display of a module is flashing the communication with this module is faulty. You can leave Module Info by actuating the -key. Page 1.8 BOGE FOCUS compressor control for screw compressors FOCUS.pm6.5 - USA... -
Page 14: Setting
00832 BLS settings If the user code, service code or BOGE code is entered it is possible to return to the previously left parameter list within 15 minutes after hav- ing left this list, without having to enter the code once more. -
Page 15: Set Parameters
, the compressor starts with the output. Pressure range 2 is only active if corresponding adjustments of the timer have been made and/or the external contact for the pressure range selection is active. Page 1.10 BOGE FOCUS compressor control for screw compressors FOCUS.pm6.5 - USA... - Page 16 To be able to do so the FOCUS control constantly monitors the air supply network and "learns" the necessary data. Thus these data are automatically kept in case of net structure changes.
- Page 17 In this case setting 1 means fault and setting 0 warning! Page 1.12 BOGE FOCUS compressor control for screw compressors FOCUS.pm6.5 - USA...
- Page 18 This parameter determines the ON/Off switching function of the control via Tan, a potential-free contact or the Bus. In case the parameter is selected unequal 0, a switching On or Off via Tan of the FOCUS is no longer possible. Setting...
- Page 19 Remote-Start-Stop function are enabled. The settings for external output release (P064) and Remote-Start-Stop (P065) have to be effectuated separately under the corresponding param- eter numbers. Page 1.14 BOGE FOCUS compressor control for screw compressors FOCUS.pm6.5 - USA...
-
Page 20: Grouped Parameters / Parameter Management
P (P1.1) and P (P1.2) of pressure range 1. By actuating the -key P (P2.1) and P (P2.2) of pressure range 2 (pres- sure decrease values) are displayed. BOGE FOCUS compressor control for screw compressors Page 1.15 FOCUS.pm6.5 - USA... -
Page 21: Timer
4. Next the priority sequence of the compressors (see chapter Basic-Load- Switching with additional compressors) can be selected. Each combina- tion of the numbers 1 – 4 is possible. Page 1.16 BOGE FOCUS compressor control for screw compressors FOCUS.pm6.5 - USA... - Page 22 -key is actuated, this setting is left without accepting the changes. In the modus 'Selection of the switching channel' the actuation of the key brings you back to the main display. BOGE FOCUS compressor control for screw compressors Page 1.17 FOCUS.pm6.5 - USA...
-
Page 23: Functions
Pressure range 2 becomes active if selected by the external contact and the timer or if the external contact is closed and no pressure range selection is made by the timer. Page 1.18 BOGE FOCUS compressor control for screw compressors FOCUS.pm6.5 - USA... -
Page 24: Parameterization Of Frequency Converter
LEDs should be illuminated. You leave the LED-Test by pressing the -key. BOGE FOCUS compressor control for screw compressors Page 1.19 FOCUS.pm6.5 - USA... -
Page 25: Warning Message / Fault Message
45 For a complete acknowledgement of the message (switch-off of the orange- (Watchdog timer reset) coloured LED) the control must be de-energized for a short time. Page 1.20 BOGE FOCUS compressor control for screw compressors FOCUS.pm6.5 - USA... -
Page 26: Fault Messages
The red LED is continuously illuminated after the acknowledgement of the fault and the compressor status display shows Fault until the fault has been rectified. Only then the compressor can be started again. BOGE FOCUS compressor control for screw compressors Page 1.21 FOCUS.pm6.5 - USA... -
Page 27: Data Of External Connections
T. spring External RS485 Signal A Input differential voltage max. +12V terminal interface T. spring External RS485 Signal B Input differential voltage max. –12V terminal interface Page 1.22 BOGE FOCUS compressor control for screw compressors FOCUS.pm6.5 - USA... -
Page 28: Analogue Output Module
TWIN-AEH without plastic sleeve max Tension spring terminals: Capacity of terminals 0.5...1.5 mm² Single wire 0.5...1.5 mm² Stranded wire 0.5...1.5 mm² with ferrule 0.5...1.5 mm² AWG- conductor 26-14 BOGE FOCUS compressor control for screw compressors Page 1.23 FOCUS.pm6.5 - USA... -
Page 29: Fault Messages
Control unit DOWN-key does not open Net pressure transmitter wire breakage Compressor system pressure transmitter wire breakage Compressor system pressure transmitter faulty Bus live bit faulty Excessive current compressor motor Page 1.24 BOGE FOCUS compressor control for screw compressors FOCUS.pm6.5 - USA... - Page 30 Control unit RIGHT-key does not open Basic module recognizes TAN error Communication with RS485 module faulty Communication with converter module faulty Communiction with analogue outlet module faulty Side duct ventilation – excess current BOGE FOCUS compressor control for screw compressors Page 1.25 FOCUS.pm6.5 - USA...
-
Page 31: Parameter Overview
Monitoring of external output release 0 ... 1 User P065 Remote/Start/Stop 0 ... 3 User P066 Key switch 0 ... 3 User Parameters can be processed as described under "Parameter Settings". Page 1.26 BOGE FOCUS compressor control for screw compressors FOCUS.pm6.5 - USA...
