PureLink HCE III Owner's Manual page 9

PureLink offers TotalWire CAT-X high performance cable for your CATx cable needs.
PureLink also offers extended warranty of HCE III Tx/Rx product when CX cables are used
together. For detail information, please contact support@purelinkav.com.
CX SERIES
TOTALWIRE™ CAT-X High Performance Cable
Certified CATx Cable with TotalWire Technology - 10m
CX-010
CX-020 Certified CATx Cable with TotalWire Technology - 20m
CX-030 Certified CATx Cable with TotalWire Technology - 30m
CX-040 Certified CATx Cable with TotalWire Technology - 40m
CX-050 Certified CATx Cable with TotalWire Technology - 50m
CX-070 Certified CATx Cable with TotalWire Technology - 70m
CX-100 Certified CATx Cable with TotalWire Technology - 100m
CX-1000 Certified CATx Cable with TotalWire Technology - 1000' Reel
RS-232 Cable Termination (for HTX receiver pass-thru)
3-pin Phoenix connector is used for RS-232 communication between HCE III Tx/Rx and connected devices.
Pin RS-232
1 Tx
2 Ground
3 Rx
* Pinout from the left
9
