1.6 Product Specifications
General Specification
Power
Power Consumption
Operational Temperature
Storage Temperature
Humidity
MTBF
Dimensions (W x D x H)
Shipping Dimensions (with cover box)
Weight
Shipping Weight
(with accessories and cover box)
Technical Specification
HDMI Version
HDCP Compliance
Data Rate
Resolution
HDMI Audio
Transmitter
Receiver
Input: AC100 – 240V 50/60Hz
Output: DC 24V/1A (US/EU standard,
CE/FCC/UL certified)
24W (max)
32° ~ 117° F (0° to 47° C)
- 4° ~ 140° F (-20° to 60° C)
0 ~ 90% non-condensing
50,000 hours
7.2'' x 3.5'' x 0.7'' (183 x 88 x 18mm)
TBD
Tx: 1.0 lbs (0.45 kg) Rx: 1.0 lbs (0.45 kg)
TBD
HDMI 2.0
HDCP 2.2
18 Gbps
Ultra HD/4K up to 4096 x 2160 @50/60Hz (RGB 4:4:4, YCbCr
4:4:4, 4:2:2, 4:2:0)
LPCM 2/5.1/7.1 Ch, Dolby Digital+, Dolby TrueHD, Dolby Digital,
Dolby Atmos, DTS:X, DTS-HD Master Audio, DTS 5.1
Inputs: 1 x HDMI Type A [19-pin female]
1 x IR input [3.5mm stereo mini-jack]
1 x RS232 [Phoenix connector]
1 x Firmware [Mini USB]
Outputs: 1 x HDBaseT [RJ45]
1 x IR output [3.5mm stereo mini-jack]
Inputs: 1 x HDBaseT [RJ45]
1 x IR input [3.5mm stereo mini-jack]
1 x RS232 [Phoenix connector]
1 x Firmware [Mini USB]
Outputs: 1 x HDMI Type A [19-pin female]
1 x IR input [3.5mm stereo mini-jack]
