Purelink HUE-100 User Manual V1.1
HUE-100
4K HDMI and USB-C Over HDBaseT 3.0
100 Meter Extension System with Bi-Direc�onal PoC
USER MANUAL
PureLink™
220-10 State Route 208
Fair Lawn, NJ 07410 USA
Tel: +1.201.488.3232
Fax: +1.201.621.6118
E-mail:
sales@purelinkav.com
For order support, please contact your local dealer.
For technical support, please contact us at support@purelinkav.com.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PureLink HUE-100
Summary of Contents for PureLink HUE-100
- Page 1 Purelink HUE-100 User Manual V1.1 HUE-100 4K HDMI and USB-C Over HDBaseT 3.0 100 Meter Extension System with Bi-Direc�onal PoC USER MANUAL PureLink™ 220-10 State Route 208 Fair Lawn, NJ 07410 USA Tel: +1.201.488.3232 Fax: +1.201.621.6118 E-mail: sales@purelinkav.com For order support, please contact your local dealer.
-
Page 2: Table Of Contents
Purelink HUE-100 User Manual V1.1 Contents Introduc�on ..............................3 Features ................................ 3 What’s in the Box ............................4 Specifica�ons ..............................4 Opera�on Controls and Func�ons ........................ 5 Transmiter Panel ............................5 Receiver Panel ............................7 IR Cable Pin Assignment ..........................8 API Commands .............................. -
Page 3: Introduc�On
The HUE-100 provides Dolby Vision, HLG, mul�-channel audio, CEC pass-through, bi-direc�onal RS-232 and IR control, and PoC – all with zero loss and zero noise. The HUE-100 also supports Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio plus LCPM. Addi�onally, the low profile “slim box” enclosure design makes the HUE-100 ideal for limited space installa�on environments, such as behind flat panel... -
Page 4: What's In The Box
Purelink HUE-100 User Manual V1.1 What’s in the Box 1 × 18Gbps HDMI/USB-C over HDBaseT 3.0 Extender (Transmiter) 1 × 18Gbps HDMI/USB-C over HDBaseT 3.0 Extender (Receiver) 1 × IR Blaster Cable (1.5 meters) 1 × IR Wideband Receiver Cable (1.5 meters) ... -
Page 5: Opera�On Controls And Func�Ons
Purelink HUE-100 User Manual V1.1 Output: DC 24V/3.75A (US/EU standard, CE/FCC/UL certified) Power Consumption 94.32W (Power supply from TX, 60W USB-C charging, POC to RX) 10.8W (Power supply from TX or RX, without USB-C (Max) charging) Operating 32 - 104°F / 0 - 40°C Temperature Storage Temperature -4 - 140°F / -20 - 60°C... - Page 6 Purelink HUE-100 User Manual V1.1 Three USB extension ports, connected to mouse, keyboard, USB Flash Drive USB Device Ports or other USB devices, with a maximum power supply of 500mA. 9 SERVICE Firmware update and API command control port. HDBaseT output port, connected to the HDBaseT IN port of receiver HDBaseT OUT with a CAT6A/7 cable.
-
Page 7: Receiver Panel
Purelink HUE-100 User Manual V1.1 Receiver Panel Name Function Description Power LED Red LED indicates that the receiver is powered on. Light on: Transmitter and receiver are in good connection status. ▪ LINK LED Light flashing: Transmitter and receiver are in poor connection status. -
Page 8: Ir Cable Pin Assignment
Purelink HUE-100 User Manual V1.1 IR Cable Pin Assignment The pin assignment of the IR Receiver cable and IR Blaster cable is as below: Note: When the angle between the IR receiver and the remote control is ± 45 °, the transmission distance is 0-5 meters;... - Page 9 Purelink HUE-100 User Manual V1.1 r fw version Get the firmware version r fw version TX 1.0.0 RX 1.0.0 Reboot… s reboot Reboot the device System Initializing... Initialization s reboot Finished! TX 1.0.0 RX 1.0.0 Sure to RESET to default settings? Type...
- Page 10 Purelink HUE-100 User Manual V1.1 Set input ports EDID x = USBC, HDMI, ALL 00 - EDID dip switch (default) 01 - 1920x1080@60 8bit Stereo 02 - WUXGA 1920x1200 03 - 1920x1080@60 8bit High Definition Audio 04 - 3840x2160@60Hz 4:2:0 Deep Color Stereo...
-
Page 11: Applica�On Example
Purelink HUE-100 User Manual V1.1 Applica�on Example... -
Page 12: Warranty
TERMS & CONDITIONS PureLink shall repair or replace the Product if it develops a material fault during the period of warranty, on condition that i) the Product has only been subject to normal use in a domestic or commercial environment in a manner consistent with its... - Page 13 Most problems can be corrected over the phone through close cooperation between Customer and a PureLink technician. To better enable PureLink to address a warranty claim, please have the Product’s serial and model numbers. If PureLink, in its sole discretion, determines that an on-site visit or other remedial action is necessary, PureLink may send a representative to Customer’s site.
