iMars grid-tied solar inverters
Inverter state
Unrecoverable
fault
Artificial
turned off
Note Please refer to chapter 6 and 8 for detailed fault information and troubleshooting.

6.2 Operation panel

There are 4 buttons on the panel:
(1) "ESC", exit and return ;
(2) " ", back to the front page and data increasing;
(3) " "，to the next page and data decreasing;
(4) "ENT", enter.
The machine can be turned on and off by pressing the buttons: press "ESC" and "ENT"(about 3
seconds) at the same time, and then the quick start-up and stop is available.
LED indicators
Run
Warn
Fault
Run
Warn
Fault
Run
Warn
Fault
Run
Warn
Fault
(1) Inverter stand-by. Temperature abnormal(E006);
(2) Inverter stand-by. DC input fault (E001);
Yellow indicator keeps on, others off
Hardware or software fault (E003, E004, E005, E008,
E009, E011, E013 or E015). De-couple the inverter
from the system before maintenance.
Red indicator blinks in every 0.5s, others off
Current-leakage or unqualified output power energy of
the inverter (E007, E010, E014, E017, E018 or E020).
De-couple the inverter from the system before
maintenance.
Red indicator keeps on, others off
Stop after the communication or panel command. All
indicators are on.
36
Description
Display panel
