36" Belt Drive
2
3

Motor Specifications and Drive Component Part Numbers

Fan Specifications (assembled)
Description Part Numbers
38589-362X
*Fiberglass
38589-364X
Cone Fan
38589-365X
38589-360X
Black 46778-362X
Fiberglass
46778-364X
Cone Fan
46778-365X
46778-360X
38946-362X
Fiberglass
38946-364X
Fan With
38946-365X
Grill
38946-360X
46777-362X
Black
46777-364X
Fiberglass
Fan with
46777-365X
Grill
46777-360X
*
Replace the "X" in fan P/N with "1" for an Aluminum Shutter, "2" for a Plastic Shutter, "4" for Gray Plastic Shutter.
MV1680H

Shutter Installation Continued....

Plastic Shutter Part Numbers

3
MV1680-014 04/02
1
4
Figure 10. Plastic Shutter Part Numbers
Motor Specifications and Drive Component Part
Numbers.
Sub- Voltage
Assembly
Part No's
38588-2 208/230
38588-4 208-230/460
38588-5 220-240/380-415
38588-LM --
46974-2 208/230
46794-4 208-230/460
46794-5 220-240/380-415
46974-LM --
38588-2 208/230
38588-4 208-230/460
38588-5 220-240/380-415
38588-LM --
46974-2 208/230
46974-4 208-230/460
46974-5 220-240/380-415
46974-LM --
Motor Specifications and Drive Component Part Numbers
Item Description
1 Shutter Assembly
2 Push Nut, 1/4"
3 Shutter Rod Pivot
4 Shutter Louver (White) 38038-2
Motor Specifications
HZ Phase HP Motor
P/N Sheave Part
60 1 .5 40158 1381 (AK27) 42338 (AK51) 39783
60 3 .5 4714 1381 (AK27) 42338 (AK51) 39783
50 3 .5 38566 8773 (AK30) 42338 (AK51) 39783
-- -- -- -- 1381 (AK27) 42338 (AK51) 39783
60 1 .5 40158 1381 (AK27) 42338 (AK51) 39783
60 3 .5 4714 1381 (AK27) 42338 (AK51) 39783
50 3 .5 38566 8773 (AK30) 42338 (AK51) 39783
-- -- -- -- 1381 (AK27) 42338 (AK51) 39783
60 1 .5 40158 1381 (AK27) 42338 (AK51) 39783
60 3 .5 4714 1381 (AK27) 42338 (AK51) 39783
50 3 .5 38566 8773 (AK30) 42338 (AK51) 39783
-- -- -- -- 1381 (AK27) 42338 (AK51) 39783
60 1 .5 40158 1381 (AK27) 42338 (AK51) 39783
60 3 .5 4714 1381 (AK27) 42338 (AK51) 39783
50 3 .5 38566 8773 (AK30) 42338 (AK51) 39783
-- -- -- -- 1381 (AK27) 42338 (AK51) 39783
Part No.
38027
(White) Plastic
Shutter Assembly 46972
(Gray) Plastic
38032
38702-2
Shutter Louver (Gray) 46715-2
Motor Fan Sheave
Part No.
No.
Belt
P/N
13
