Fan Installation
1 2
8

Planning the Installation Continued....

4
1 2
1 2
Rough Frame
Opening
45.38" 43.00"
(115.27 cm) (109.22 cm)
Figure 2. Planning and Layout Diagram for Grill Fans

Installing the Fan to the Framed Opening

1. Cut an opening in the wall to house the fan—the required wall opening is
provided in the chart below. See Figure 3.
2. Construct a frame in the opening of the wall for the fan using 2" x 6" (50
x 152 mm) lumber—not supplied.
Minimum Dimension
1
43.00"
(109.22 cm)
Figure 3. Framing Diagram
1
2
3
3 4
Minimum
0" 27"
(0.00 cm) (68.58 cm)
1
2
Mv1680-010 02/01
2
43.00"
(109.22 cm)
36" Belt Drive
Mv1680-009 02/01
MV1680H
