36" Belt Drive

Planning the Installation

Fan Installation

1 2
5
(115.27 cm)
MV1680H

Decal Location

This diagram shows the proper location of the Safety Decal and a Identification
Decal (the identification decal will be different depending on the type of fan
purchased) as shipped from the factory. Replace damaged or missing decals. Make
sure the decals can be easily seen at all times.
Planning the Installation
Carefully plan the installation.
Dimensions are provided for the 36" TURBO
without Cones (Figure 2). Be sure to allow enough space to install fans without
interfering with other fans or equipment that may be installed at a later date.
Note: See page 8 for framed opening size.
Important: Cones are wider than the actual opening cut into wall. Thus,
dimension "3" must be no less than that listed in chart below.
4
1 2
1 2
Rough Frame
Opening
45.38" 43.00"
(109.22 cm) (20.32cm)
Figure 1. Planning and Layout Diagram for Cone Fans
Mv1680-003 02/01
®
1
2
3 4
Minimum
8.00" 47.00"
(119.38 cm) (17.40 cm)
Fan Installation
Fans with Cones (Figure 1) and
6
Mv1680-008 02/01
3
5 6
6.85" 52.38"
(133.05 cm)
7
