Shutter Louver Installation Continued; (Optional) Mounting Kit - Chore-Time MV1666B Installation Manual

Fan Assembly Procedure
1
2
3
36'' Shutter Fan Mounting Kit Part Number 44456
1 Top 36'' Shutter Fan Mount
2 Side 36'' Shutter Fan Mount
3 Mounting Kit Package Hardware
18

Shutter Louver Installation Continued....

Slide the next Shutter Louver on the opposite end of the Shutter Pivot Rod, Bend the
Shutter Pivot Rod - Shutter Louver combination and insert the free end of the Shutter
Pivot Rod into the second hole up from the bottom of the other Side
Panel. (See Figure 14)
4 Mv1666-015 01/01
1
Repeat these steps for the remaining Shutter Pivot Rods and Shutter Louvers.

(Optional) Mounting Kit

Figure 15 shows the optional Mounting Kit available through your local dealer.
3
2
44402
44403
44506
Figure 15. Optional Mounting Kit
Item Description
1 Shutter Louver
2 Center Rails
3 Shutter Pivot Rod
4 Bottom Side Panel
5
5 Side Panel
Figure 14. Installing the second Shutter Louver
1
2
Mv1666-018 01/01
1
48'' Shutter Fan Mounting Kit Part Number 44455
1 Top 36'' Shutter Fan Mount
2 Side 36'' Shutter Fan Mount
3 Mounting Kit Package Hardware
36" & 48" Shutter Box Fan
44400
44401
44507
