Led Diagnostics; Maintenance; Terminal Identification; Wiring Distance Table - Altronix STRIKEIT2 Installation Manual

LED
AC Power Green
Red
Unit should be tested at least once a year for the proper operation as follows:
Output Voltage Test:
Battery Test:
Caution:
Terminal Legend
– AUX +
– BAT +
– OUT +
GND / NO
InRush
Wire Gauge
Current
8A 14 AWG Stranded
8A 12 AWG Stranded
12A 14 AWG Stranded
12A 12 AWG Stranded
16A 14 AWG Stranded
16A 12 AWG Stranded
- 4 -

LED Diagnostics:

LED Status Panic Device Power Controller Status
On Normal operating condition .
Off Loss of AC .
On 24VDC present on the output (unit is triggered) .
Off Loss of 24VDC on the output (unit is not triggered) .
Under normal load conditions the DC output voltage should be checked for proper
voltage level .
Under normal load conditions check that the battery is fully charged, check specified
voltage both at battery terminal and at the board terminals marked [– BAT +] to
ensure that there is no break in the battery connection wires .
Note: Maximum charging current under discharge is 300mA .
Note: Expected battery life is 5 years; however, it is recommended changing
batteries in 4 years or less if needed .
For continuous protection against risk of electric shock and fire hazard, replace input
fuse with the same type and rating 6 .3A/250V . Do not expose to rain or moisture;
indoor use only .

Terminal Identification:

Function/Description
23 .2-24VDC Auxiliary Output @ 0 .5A .
23 .2-24VDC Stand-by Battery Connection (Two (2) 12VDC batteries wired in series) .
Connect 24VDC Panic Hardware Device, up to 16A for 300 ms ., 0 .5A on hold .
Normally Open [NO] trigger input controls output .
A maintained contact closure will extend the unlock period .

Wiring Distance Table:

Max distance from Power Supply

Maintenance:

Electric Butt or Pivot
to frame side of opening
75 ft .
175 ft .
60 ft .
80 ft .
40 ft .
60 ft .
EPT
Max distance from Power Supply to
frame side of opening
100 ft .
200 ft .
75 ft .
100 ft .
75 ft .
80 ft .
StrikeIt2
