Unplug connector
i233-411
www.powercommander.com
PCIII connectors
Stock connectors
PCIII ground wire
6
Unplug the main wiring harness from
the throttle bodies (Fig. D).
This is a 16 pin BROWN connector
located under the fuel tank on the
right hand side of the bike
7
Plug the PCIII connectors in-line of
the stock wiring harness and throttle
body harness (Fig. E).
8
Attach the ground wire of the PCIII
to the negative side of the battery
(Fig. F).
2008 Kawasaki ZX10R - PCIII USB - 3
