Parts List
1
Power Commander
1
USB Cable
1
CD-ROM
1
Installation Guide
1
Power Adapter
2
Power Commander Decals
2
Dynojet Decals
2
Velcro
Strip
®
1
Alcohol Swab
1
O2 eliminator
The ignition MUST be turned
OFF before installation!
You can also download the Power
Commander software and latest maps
from our web site at:
www.powercommander.com
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89081 (800) 992-4993 www.powercommander.com
i625-411
www.powercommander.com
2008 Husqvarna TE250
Installation Instructions
Button Adjustment Display
Faceplate Buttons
Expansion Port
2008 Husqvarna TE250 - PCIII USB - 1
USB Port
Advertisement
Table of Contents
Related Manuals for Dynojet POWER COMMANDER III
Summary of Contents for Dynojet POWER COMMANDER III
-
Page 1: Installation Instructions
Commander software and latest maps from our web site at: www.powercommander.com PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89081 (800) 992-4993 www.powercommander.com i625-411 www.powercommander.com 2008 Husqvarna TE250 - PCIII USB - 1... - Page 2 Remove the seat. Remove the fuel tank. Using the supplied velcro attach the PCIII to the inner side of the right hand side cover (Fig. C). Make sure to clean both surfaces with the alcohol swab before attaching. Attach the ground wire from the PCIII to the negative side of the battery (Fig.
- Page 3 (Fig. F). Unplug this connection and install the Dynojet O2 eliminator onto the stock wiring harness. The O2 sensor will not be connected to any- thing at this time. It can be removed from the exhaust if desired.
