6.4

The Menue Tree

In the following, the display and adjustment options are described by their position in the
menue tree. An overview of the menue tree can be found on the last page of this docu-
ment.
6.4.1 Main menue
The main menue has the following entries:
Menue entry
Quick setup
Adjustment
Display
Measurem./Output
Diagnosis
Simulation
Communication
System
6.4.2 Menue "Quick Setup"
In Quick Setup, basic configuration options are combined to make it possible to quickly
configure key functions. All functions of the quick setup can also be found at another posi-
tion in the menue tree.
The following functions are available in the Quick Setup menue:
Menue entry
Language
Pressure unit
Lower range val.
Upper range val.
Damping
Device ID
BA_080 Rev 1J8 Pressure transmitter PASCAL CV4
Description
Selection of the most important settings
Adjustment functions for pressure measurement and current out-
put
Functions for configuring the display
Configuration of the pressure measurement and current output
Diagnostic information such as min/max values
Simulation of pressure and current for function check of the
measurement chain
Information and settings regarding HART communication
Device data and function such as factory reset
Table 6: The main menue
Description
Select menue language
Select unit for measured pressure (see 6.4.4.1)
Setting of the pressure value that should correspond to 4 mA
(start of range) (see 6.4.5.3)
Setting of the pressure value that should correspond to 20 mA
(end of range) (see 6.4.5.3)
Setting the damping of the output signal (see 6.4.5.1)
Setting the device ID (see 6.4.9.1)
Table 7: "Quick-Setup" menue
