6.4.4 Menue "Display"
In the "Display" menue, you find all the settings that affect the display on the screen.
Menue entry
Language
Units
Screen mode
Decimal point
Backlight
6.4.4.1 Submenue "Units"
You can select the unit of every value shown on the display. These settings do not affect
the internal calculations of the device or HART communication.
The shown conversions are only meant for your orientation. The device uses conversion
values with ten decimal places.
BA_080 Rev 1J8 Pressure transmitter PASCAL CV4
Description
Select menue language
Setting units for the different measured and displayed values
Configuration of the screen layout and content (see 6.2.4)
Select setting of decimal point to determine number of decimal places
Switch backlight on/off
Table 10: "Display" menue
