Cable Specifications; Control Input/Output And Control Data - Danfoss VLT Midi Drive FC 280 Instruction Manual

Specifications
EMC standards, immunity
2)
Energy efficiency class
1) Refer to Special Conditions in the Design Guide for:
•
Derating for high ambient temperature.
•
Derating for high altitude.
2) Determined according to EN50598-2 at:
•
Rated load
•
90% rated frequency
•
Switching frequency factory setting
•
Switching pattern factory setting

9.5 Cable Specifications

Cable lengths and cross-sections
Maximum motor cable length, shielded
Maximum motor cable length, non-shielded
Maximum cross-section to control terminals, flexible/rigid wire
Minimum cross-section to control terminals
Maximum STO input cable length, unshielded
1) For power cables, see Table 9.1 to Table 9.2.

9.6 Control Input/Output and Control Data

Digital inputs
Terminal number
Logic
Voltage level
Voltage level, logic 0 PNP
Voltage level, logic 1 PNP
Voltage level, logic 0 NPN
Voltage level, logic 1 NPN
Maximum voltage on input
Pulse frequency ranges
(Duty cycle) minimum pulse width
Input resistance, R
i
1) Terminals 27 can also be programmed as output.
1)
STO inputs
Terminal number
Voltage level
Voltage level, low
Voltage level, high
Maximum voltage on input
Minimum input current (each pin)
1) Refer to chapter 6 Safe Torque Off (STO) for more details about STO inputs.
MG07A122
Instruction Manual
1)
Danfoss A/S © 11/2015 All rights reserved.
EN 61000-3-12, EN 61000-6-3/4, EN 55011, IEC 61800-3
EN 61800-3, EN 61000-6-1/2, EN 61000-4-2, EN 61000-4-3
EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61326-3-1
IE2
50 m (165 ft)
75 m (250 ft)
2.5 mm 2 /14 AWG
9
0.55 mm 2 /30 AWG
20 m (65 ft)
1)
18, 19, 27 , 29, 32, 33
PNP or NPN
0–24 V DC
<5 V DC
>10 V DC
>19 V DC
<14 V DC
28 V DC
4–32 kHz
4.5 ms
Approximately 4 kΩ
37, 38
0–30 V DC
<1.8 V DC
>20 V DC
30 V DC
6 mA
51
9
