Electrical Installation
1
9
10
L1
L2
L3
PE
1 PLC
2 Adjustable frequency drive
3 Output contactor (generally not recommended) 8
4 Grounding rail (PE)
5 Cable shielding (stripped)
Figure 4.3 Typical Electrical Connection
MG07A122
Instruction Manual
2
Status Quick Main
Menu Menu
Menu
OK
Hand Auto
Reset
On On
8
6 Minimum 200 mm (7.9 in) between control cables, motor and line
power.
7 Motor, 3-phase and PE
Line power, single-phase, 3-phase and reinforced PE
9 Control wiring
10
Equalizing minimum 16 mm
Danfoss A/S © 11/2015 All rights reserved.
3
4
6
7
2
(6 AWG)
4 4
5
U
V
W
PE
13
