Programming

5. Programming
The LCD display with 4 lines and 20 digits shows following information:
Line Uni-directional
1 Meter type, software version and alternating error messages
2 Flow velocity (v)
3 Flow rate (R)
4 Totalizer T1
5 Totalizer T2
6 Pre-selection volume (PS)
7
Uni-directional
M - S e r i e s
v =
R = 0 . 0 0 0 0 0 0
T 1
T 2
P S
The display can be scrolled by using the up ▲ and down ▼ buttons.
Programming is accomplished by using the three functional buttons ▲(+),▼(-) and E(►).
You can move from the measuring mode to the programming mode by pressing twice the
button E. While first pressing this button, you activate the backlight and while pressing it for
a second time, you get into the programming menu.
The cursor → on the left side of the display is moved upward and downward with the buttons
▲▼. The menu manager or selection from a list is marked with the cursor and
acknowledged by pressing the button E.
To enter a parameter, the first number is marked with an underline 0. By pressing the
buttons + / -, you can increment or decrement them. As soon as the requested number has
been selected, you can acknowledge it by pressing the button E. After having entered the
last number, the value is stored by pressing the button E or press the button + in order to
edit the value again.
You get access to the individual menus through three programmable access levels:
Administrator, service and user level.
Access rights of the individual menu items is shown in the following with three symbols:
Administrator
For programming the access levels, see the chapter "passwords".
No passwords were set at the factory.
Totalizer T+
Totalizer T-
Net. totalizer TN
Pre-selection volume (PS)
Bi-directional
V 1 . 1 4
0 . 0 0 0 0 m / s
M 3 H
0 M^3
0 M^3
0 M^3
Service
MID_M2000_BA_02_1807
Bi-directional
M - S e r i e s
v = 0 . 0 0 0 0
R = 0 . 0 0 0 0 0 0
T +
T -
T N
P S
User
Page 14/51
V 1 . 1 4
m / s
M 3 H
0 M^3
0 M^3
0 M^3
0 M^3
