6.7 Control Board

Automatic Master's control board was designed to meet most technologies of
access control terminals in the market. The controller have mechanical features
and layout perfectly suited for the Automatic Master's needs and it is one of the
best options for the equipment's operation.
The following images show the control board with its straps, connectors, and
dipswitch, as well as the location of the power supply and the control board in
Automatic Master.
CONNECTOR
CN8
CONNECTOR
CN9
Ds1
Ds2
The table below describes the functions of the control board's connectors:
