6.Installing/assembling optional
items
Automatic Master is compatible with most access control technologies in the market
today; however, Digicon offers a range of optional items that allow enhancing and
matching the equipment's performance to the client's needs. See the description of
each of these items:

6.1 Rear closure kit

Automatic Master can be provided with a panel to close the rear space between the
columns. The sheet can be of 6 mm tempered glass, 6 mm acrylic, or and 1.2 mm
stainless steel, as the client sees fit. Besides closing the rear space, the panel allows
simple customization with low cost.
The rear closure kit is mounted has four fasteners that secure the sheet to the side
columns, as shown below:
8
R2,25
B
Detail 4x
A
784
6
15
