5.4 Accessing the turnstile after assembly
After Automatic Master is installed and assembled, access to the interior of the
equipment can be done with the key that accompanies the equipment, in three ways:
external covers, central cover, or column door.
See now the instructions for opening Automatic Master after assembly:
1. Unlock the two extremities of the Automatic Master, using the key provided
alongside the product. Remove the external covers, which are pressed into place. The
covers feature small internal couplings that support them in the column during
operation, as can be seen in the image to the right.
LOCK
2. Before opening the central cover, deactivate the security pins located on each side
of the cover.
FIT THE PINS OF THE
EXTERNAL COVER
