Passage confirmation through disk emulation
Rl1
1
Rl2
1
Passage confirmation through clockwise pulse
Rl1
1
Rl2
1
Passage confirmation through ''disk emulation'' can be set through dip switch Ds2,
nº7 in case it's on it'll emulate disk. On the other hand it's off, it'll general pulse.
Passage confirmation(negative)
Digital negative input
Integrator's controller
4321
30
