6.7.4 Turnstile Interface

Enabling through Dry contact with 2 relays:
Enabling both ways (Clockwise and Counter Clockwise) with 1 single relay:
7654321
7654321
Dry contact
Enabling
Clockwise
Enabling
Counter Clockwise
Dry contact (simultaneos)
Relay
Integrator's controller board
