DVI Connector

Connecto 29 Pin
r size
Connecto DVI-I
r type
Connecto DVI1
r location
Connecto
Pin
r pin
definition
C1
C3
C5
Connecto
r map
User's Manual
Signal
1 DVI_TX2N
3 GND
5 +12V
7 DVI_DDC_DATA
9 DVI_TX1N
11 GND
13 Hub USB_1P
15 GND
17 DVI_TX0N
19 GND
21 CRT_SCLK
23 DVI_CLKP
CRT_RED
CRT_BLUE
CRT_GND
3.0 External Connector Specification
Pin Signal
2 DVI_TX2P
4 +5VSB
6 DVI_DDC_CLK
8 CRT_VSYNC
10 DVI_TX1P
12 Hub USB_1N
14 DVI_VCC+5V
16 DVI_HPD
18 DVI_TX0P
20 CRT_SDATA
22 NC
24 DVI_CLKN
C2 CRT_GREEN
C4 CRT_HSYNC
DVI1
Page 3-2
