2.10 LINE IN JST Connector
Connecto
1X5 = 5 Pin
r size
Connecto
JST-2.0mm-M-180
r type
Connecto
LINE_IN1
r location
Connecto
Pin
r pin
definition
Connecto
r map
User's Manual
Signal
1
LINE IN R
3
LINE IN JD
5
GND
LINE IN1
2.0 Internal Connector Specification
Pin
Signal
2
LINE IN L
4
GND
Page 2-14
