2.8
USB JST Connector (USB3)
Connecto
2 X 4 = 8 Pin
r size
Connecto
JST-2.0mm-M-180
r type
Connecto
USB3
r location
Connecto
r pin
definition
Connecto
r map
User's Manual
Pin
Signal
1
5VSB
3
HubUSB_2N
5
HubUSB_2P
7
GND
2.0 Internal Connector Specification
Pin
Signal
2
5VSB
4
HubUSB_3N
6
HubUSB_3P
8
GND
USB3
Page 2-12
