2.0 INTERNAL CONNECTOR

2.1

MINI PCI-E Connector (MINICARD1)

Connector size 2 X 26 = 52 Pin
Connector type MINI PCI-E CON 9.2mmH
Connector MINICARD1
location
Connector pin
definition
User's Manual
Pin Signal
1 PCIE_WAKE#
3 NC
5 NC
7 NC
9 GND
11 NC
13 NC
15 GND
17 NC
19 NC
21 GND
23 NC
25 NC
27 GND
29 GND
31 NC
33 NC
35 GND
37 GND
39 3VSB
41 3VSB
43 GND
45 NC
47 NC
49 NC
51 NC
2.0 Internal Connector Specification
Pin Signal
2 3VSB
4 GND
6 NC
8 UIM_PWR_A
10 UIM_DAT_A
12 UIM_CLK_A
14 UIM_RST_A
16 NC
18 GND
20 MINICARD0_DIS#
22 PCIE_RST#
24 3VSB
26 GND
28 NC
30 NC
32 NC
34 GND
36 USB_4N
38 USB_4P
40 GND
42 LED_WWAN_A#
44 NC
46 NC
48 NC
50 GND
52 3VSB
