PCIII harness
i209-411
i209-411
www.powercommander.com
www.powercommander.com
Disconnect these lines
Squeeze this line to remove
Loosen these bolts
1
Remove the main seat and the
passenger seat.
2
Remove the fuel tank
Note: The installation can be done
without removing the fuel tank
but it may be easier to have it
removed
3
To remove the fuel line squeeze
the sides of the connector
(Fig. A).
Disconnect the two
electrical connectors.
4
Loosen the four bolts holding on
the left hand side cover (Fig. B).
5
Route the PCIII harness between
the tray and the frame (Fig. C).
2003-2007 Kawasaki VN1600 - PCIII USB - 2
