About the Embedded
Module
C
Overview
Digi Connect EM and Digi Connect Wi-EM Overview
The embedded modules are part of the Digi Connect family of device servers that provide
simple, reliable and cost-effective network connections for serial devices. They provide
fully transparent serial device connectivity over industry-standard Ethernet connections
and allow both equipment manufacturers and systems integrators to network-enable
products at a fraction of the time and cost required to develop a custom solution. It is a
highly flexible and compact single component solution with a robust on-board TCP/IP
stack and 10/100 Base-T Ethernet or wireless support. Features include the following:
H
A
P
T
E
R
32-bit NS7520 processor with ARM7TDMI core
4MB Flash and 8MB RAM on board
2 High Speed Serial Ports
9 Mbps SPI Master Mode Interface
9 General Purpose Input/Output Port Options
Available with Digi plug-and-play firmware
NetSilicon NET+Works platform for embedded software development
1
9
