Connectors: Antenna

The Digi Connect Wi-EM has 2 RP-SMA antenna connectors labeled P2 and P3.
Wi-EM Antenna Connectors
1 6
D i g i C o n n e c t E M & D i g i C o n n e c t W i - E M H a r d w a r e R e f e r e n c e
Caution: This Part 15 radio device operates on a non-interference basis
with other devices operating at this frequency when using the antennae
listed in the Antenna Specification table. Any changes or modification to
the product not expressly approved by Digi International could void the
user's authority to operate the device.
Antenna Specifications
Type
Part number
Gain
Dipole
DC-ANT-24DP
2 dBi
