Connectors and Blocks

The development board provides the following connectors and blocks:
JTAG Debugger Connector (P4)
This 14-pin male vertical header labeled P4 mates with a JTAG debugger plug (for
example, a Macraigor Raven). It is used with the development kit only. See the following
figure and table for pin orientation and assignments.
GPIO Port Pin Assignments
Pin
JTAG Debugger Connector (P4)
SPI Connector (P11) and SPI Jumper Block
Logic Signal Analyzer Header (P6)
Main Connector (P8)
A b o u t t h e D e v e l o p m e n t B o a r d
Signal Name
1 GND
2 GPIO-9
3 GPIO-8
4 GPIO-7
5 GPIO-6
6 GPIO-5
7 GPIO-4
8 GPIO-3
9 GPIO-2
10 GPIO-1
2 5
