Digi Connect EM Hardware Reference Manual page 35

Test Point Descriptions
Test Board
Point Label
TP11 IO-1
TP12 IO-2
TP13 IO-3
TP14 IO-4
TP15 IO-5
TP17 3.3V
TP20 RESET Reset (active low)
TP21 E+
TP22 E-
TP23 V-IN
TP24 GND
TP25 GND
TP26 IO-8
TP27 IO-7
TP28 IO-6
TP29 IO-9
A b o u t t h e D e v e l o p m e n t B o a r d
Description
GPIO-1
GPIO-2
GPIO-3
GPIO-4
GPIO-5
3.3V Supply
Ethernet Power +
Ethernet Power -
9-30 VDC Input
Ground
Ground
GPIO-8
GPIO-7
GPIO-6
GPIO-9
3 5
