LPOD C-/Ku-Band Outdoor Amplifier/Block Up Converter
Ethernet Management
4.5

Web Server (HTTP) Interface

The sections that follow describe the functionality of the LPOD Web Server (HTTP) Interface.
Please refer to the Remote Commands Specifications tables found in Appendix B. REMOTE
CONTROL for detailed descriptions of the configuration parameters featured on the individual
Web pages shown in this chapter.
4.5.1 Web Server Page Introduction
The embedded Web Server application provides the user with an easy to use interface to
configure and monitor all aspects of the LPOD. These Web pages have been designed for optimal
performance when using Microsoft's Internet Explorer Version 5.5 or higher (the examples
shown use Internet Explorer Version 6.0).
The user can fully control and monitor base operations of
the LPOD from the Web Server Interface. By rolling the
cursor over the navigation tabs located at the top of each
page (right), the user can select from the available nested
hyperlinks.

4.5.2 Enabling the Web Server Interface

To enable the Web Server Interface in the LPOD using only a 100BaseTx remote interface (this
assumes the user is running an Microsoft Windows OS):
1. Select Start, then Run,
then type "cmd" to open
the command prompt
window:
2. Start a Telnet session with
the unit at the default IP
address of 192.168.1.4:
