DIO 4 in/out of TB10 Female
TB10 Pin No .
1
2
3
4
5
6
7
8
9
10
Introduction
rBOX101-FL Series User's Manual
Signal name
XCOM+
Plus Common for DIO
DI0
DI1
DI2
DI3
DO0
DO1
DO2
DO3
XCOM-
Minus Common for DIO
Pin 10
Pin 1
Meaning
7
