1.2.7 LAN
LAN 1 :
． GBE Intel 82574, 10/100/1000Mbps LAN w/
Magnetic Isolation Protection 1.5KV
．
LED definition: Active LED (Yellow flashing), 10
LAN LED (NO Light), 100 LAN LED (Green Light), 1000 LAN
LED (Orange Light)
LAN 2 :
． FE Davicom DM9102HI, 10/100Mbps LAN w/
Magnetic Isolation Protection 1.5KV
． LED definition: Active LED (Yellow flashing), 10
LAN LED (NO Light), 100 LAN LED (Green Light)
1.2.8 Storage
1 x CompactFlash TypeII
1.2.9 USB
2 x USB2.0
With power distribution control and over current
protection
1.2.10 COM
2 ports DB9 Pin Define RS-232/422/485
ESD Protection 15KV
Magnetic Isolation Protection 2KV
The interface select by software or BIOS.
It also supports Auto Flow Control in RS485 mode
COM1,COM2 speed up to 115.2kbps
COM3-COM4 Serial Port Speed up to 921.6kbps
(rBOX101-4COM)
COM3-COM6 Serial Port Speed up to 921.6kbps
(rBOX101-6COM)
