rBOX101-FL Series User's Manual
DIO Control
DI & DO
Jumper
State
1-2
(Default)
DI to COM -
DRY
1-2
(Default)
DI to COM -
WET
External
2-3
power
WET
to DI
COM+ to DO
8
Operation
Internal power 5V for DI,
DI to COM-, Photocoupler is active
low
External power 0~24V,
DI to COM-, Photocoupler is active
low
Each DI
independent external power input
0~24V
0~24V, Photocoupler is active low
Load connector Do port to COM+
Logic level 1 : LAOD is enable
Logic level 0 : LOAD is disable
port connector
Introduction
to
