- The LED always ON without
any flash for a long time, the
OS is possible crashed.
- The LED isn't ON for a long
time, it means the system is on
shutdown status.
COM TX1
When COM1 transmit data the
LED will on.
COM RX1
When COM1 receive data the
LED will on.
COM TX2
When COM2 transmit data the
LED will on.
COM RX2
When COM2 receive data the
LED will on.
NOTE When the system is shoutdown after, if users press the
Reset Button for 3 seconds and the system will be
restarded.
