Table of Contents

Type

No.

Fault

Gas valve modulator

ALL

disconnected

Incorrect configuration

ALL

of the open /sealed

chamber

Smoke probe

ALL

intervention

ALL

Smoke probe fault

Fan check cable

ALL

disconnected

ALL

Condensate level fault

Maximum number of

ALL

consecutive releases

Return sensor (SR)

ALL

fault

Fault due to low

ALL

network voltage

Incorrect network

ALL

frequency detected

Flame loss more than 6

ALL

consecutive times

ALL

Button fault

Open Therm

ALL

communication fault

No flame valve opening

ALL

time sum anomaly

Self-calibrating

ALL

procedure is required

HP high pressure time

ALL

max. interventions

Incorrect positioning of

ALL

the delivery sensor

EV current max/min

ALL

absolute limits error

EV current upper limit

ALL

error

EV current lower limit

ALL

error

Fault on the valve

ALL

control logic line

Block due combustion

ALL

during start-up

Block due to numerous

ALL

combustion control

failures

Solution

- Check the electrical

connection

- Set the parameter tS 0.4

(Combustion configuration)

to 0

- Check the sensor is

working

- Replace the smoke probe

- Check the electrical

connection of the smoke

probe

- Contact the Technical

Assistance Centre

- Check the connection cable

between the fan and the

board

- Check for any clogging in

the pipe which takes the

condensate to the siphon

- Check that the siphon is

not clogged

- Contact the Technical

Assistance Centre

- Replace the return probe

- Check parameters

- Contact the Technical

Assistance Centre

- Check the voltage

- Contact your network

provider

- Contact your network

provider

- Check the detection

electrode

- Check the gas supply (open

valve)

- Check mains gas pressure

- Check that buttons are

working

- Check the electrical

connection of the remote

control

- Replace the board

- Carry out the self-

calibrating procedure (see

the specific section)

- Decrease setting PAR 46

- Contact the Technical

Assistance Centre

- Check that the delivery

sensor is attached to the

delivery pipe

- Check gas valve and board

- Check/replace the

connection cable to the gas

valve

- Check for blockage in

chimney or recirculation

- Bleed the air from the gas

circuit

- Check for any dirt on the

air evaporator

- Check electrode

- Check outlets

- Check air diaphragm

- Check gas calibration

- Check for any dirt on the

air evaporator

Type

No.

Fault

Irregular combustion

ALL

(temporary error)

Flow rate reduced

ALL

for (presumed) low

pressure on mains gas

Internal error (board

ALL

component protection)

Unstable combustion

ALL

feedback signal error

Combustion set cannot

ALL

be reached error

System has reached

maximum air

ALL

correction error (at the

minimum flow rate)

Combustion set cannot

ALL

be reached error

Flame signal micro

ALL

interruptions error

Block due to clogging

ALL

in smoke outlet

SW error, board start-

ALL

General board error

Frequent relief valve

ALL

intervention

Limited production of

ALL

domestic hot water

8.7.1
