Structure

Fan
1
Expansion vessel
2
Combustion chamber
3
Dual sensor (thermal safety/
4
delivery)
Compressor
5
Diverter valve
6
System filling unit
7
Domestic hot water sensor
8
Control panel
9
Domestic hot water heat
10
exchanger
Gas valve
11
Domestic water filter and flow
12
regulator
System relief valve
13
Air inlet probe (SIA) housing
14
14
27
2
3
4
5
6
7
8
9
Boiler drain
15
System pump
16
Water pressure transducer
17
Return probe
18
Automatic bleed valve
19
Water/gas capacitor
20
Burner
21
Ignition/detection electrode
22
Primary heat exchanger
23
Air evaporator
24
Inspection cover
25
Air inlet
26
Smoke outlet
27
Air inlet probe (SIA) housing
28
1 26
10 11
25 24
16
13
12
23
22
21
20
19
18
17
15
14
Fig. 10
