Communications

ReliaGATE 10-20 offers connectivity to a wide range of wireless protocols including GPS, Wi-Fi (IEEE 802.11), and
IEEE 802.15.4/ZigBee
Gigabit Ethernet, EIA-232/485 serial, and CAN 2.0b.
The ReliaGATE 10-20 provides cellular connectivity via pre-certified ReliaCELL modules, which secure directly to
the front panel.
Wi-Fi (IEEE 802.11)
Connector
Mating connector
The ReliaGATE 10-20 includes a Wi-Fi adapter. Connect an external antenna to the "WIFI" SMA connector for
the frequency ranges your application will use (2.4 GHz and/or 5 GHz).
See the System Specifications section for additional details.
GPS
Connector
Mating connector
The ReliaGATE 10-20 includes a multi-channel GPS receiver for accurate location information worldwide.
Connect an external GPS antenna to the GPS SMA connector to enable GPS functionality. The antenna should
support a frequency of 1575.42 MHz (GPS L1). For quick signal acquisition and greatest accuracy, the antenna
should be mounted with visibility to a wide area of the sky in order to receive signals from multiple positioning
satellites.
See the System Specifications section for additional details.
ReliaCELL Docking Bay: USB/Cellular, SD, SIM, Debug
The docking bay is designed to accept a ReliaCELL cellular module. When installed, the ReliaCELL covers Secure
Digital, SIM, OTG, and debug connectors.
ReliaCELL Port
Connector
Mating connector
The ReliaGATE 10-20 includes a docking bay for the ReliaCELL 10-20, a family of cellular modem modules that
are certified for networks, technologies, and carriers around the world.
18
®
. The ReliaGATE 10-20 also includes interfaces for wired connectivity such as USB 2.0,
SMA connector (outside threads) with center receptacle
SMA cable with nut (inside threads) and center pin
SMA connector (outside threads) with center receptacle
SMA cable with nut (inside threads) and center pin
USB Type A socket
M2.5 threaded mounts (4x)
ReliaCELL 10-20 (USB)
M2.5 x 20 screws (4x)
(Eurotech mounting kit 250128-90501)
