USB-DIO96H User's Guide

Environmental

Parameter
Operating temperature range
Storage temperature range
Humidity

USB specifications

Parameter
USB "B" connector
USB device type
Device compatibility
USB cable type
USB cable length

Data transfer rates

Parameter
Digital I/O transfer rates
(software paced)
Counter/timer read/write rates
(software paced)

Mechanical

Parameter
Board dimensions (L × W × H)
Enclosure dimensions (L × W × H)

Screw terminal connectors

Parameter
Connector type
Wire gauge range
Table 4. Environmental specifications
Specification
0 °C to 60 °C
–40 °C to 85 °C
0% to 90% non-condensing
Table 5. USB specifications
Specification
Input
USB 2.0 (full-speed)
USB 1.1, USB 2.0 (hardware revision G and later are also compatible with USB 3.0; see
Note 1 on page 15 for information on how to determine the hardware revision)
A-B cable, UL type AWM 2527 or equivalent. (min 24 AWG VBUS/GND,
min 28 AWG D+/D–)
3 m (9.84 ft) max
Table 6. Data transfer rate specifications
Specification
System dependent, 33 to 250 port reads/writes or single bit reads/writes per second typ
Counter read – system dependent, 33 to 250 reads per second
Counter clear – system-dependent, 33 to 250 writes per second
Table 7. Mechanical specifications
Specification
304.8 × 121.9 × 20.0 mm (12.0 × 4.8 × 0.8 in.)
342.9 × 125.7 × 58.9 mm (13.50 × 4.95 × 2.32 in.)
Table 8. Connector specifications
Specification
Screw terminal
14 AWG to 30 AWG
17
Specifications
