Summary of Contents for Measurement Computing USB-DIO96H
- Page 1 USB-DIO96H High-drive Digital I/O User's Guide Hardware Revision 2 June 2016. Rev 12A © Measurement Computing Corporation.
- Page 2 Other product and company names mentioned herein are trademarks or trade names of their respective companies. © 2016 Measurement Computing Corporation. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form by any means, electronic, mechanical, by photocopying, recording, or otherwise without the prior written permission of Measurement Computing Corporation.
-
Page 3: Table Of Contents
What you will learn from this user's guide ......................4 Conventions in this user's guide ......................... 4 Where to find more information ......................... 4 Chapter 1 Introducing the USB-DIO96H ....................... 5 USB-DIO96H block diagram ..........................6 Chapter 2 Installing the USB-DIO96H ........................7 Unpacking................................ -
Page 4: Preface
This manual covers revision 2 hardware and later This manual covers revision 2 of the USB-DIO96H hardware, which uses a 5 V power supply. Revision 1 of the USB-DIO96H hardware has a 9 V power supply and daisy-chained hub. For information on revision 1 hardware, refer to www.mccdaq.com/pdfs/manuals/USB-DIO96H_R1.pdf. -
Page 5: Introducing The Usb-Dio96H
This manual covers revision 2 hardware and later This manual covers revision 2 of the USB-DIO96H hardware, which uses a 5 V power supply. Revision 1 of the USB-DIO96H hardware has a 9 V power supply and daisy-chained hub. For information on revision 1... -
Page 6: Usb-Dio96H Block Diagram
USB-DIO96H User's Guide Introducing the USB-DIO96H USB-DIO96H block diagram USB-DIO96H functions are illustrated in the block diagram shown here. Figure 1. USB-DIO96H functional block diagram... -
Page 7: Installing The Usb-Dio96H
Refer to Figure 2 on page 9 for the POWER IN location of this connector. LED lights up when +5 V power is supplied to the USB-DIO96H. If the voltage supply is less than +4.1 V or more than +5.6 V, the LED does not turn on. - Page 8 Plug the external power cord back into the connector. POWER IN Plug the USB cable back into the USB-DIO96H. Your system should now properly detect the USB-DIO96H hardware. Contact technical support if your system still does not detect the USB-DIO96H.
-
Page 9: Functional Details
The USB-DIO96H has an external power connector labeled on the enclosure and on the board. POWER IN Connect the connector to the supplied +5 V external power supply (PS-5V3AEPS). When running POWER IN at full load, the USB-DIO96H draws 2.7 A from the supply. -
Page 10: Molex Connector
Molex connector Figure 4. JP2 configuration modes USB LED LED turns on to indicate the communication status of the USB-DIO96H. It uses up to 5 mA of current and cannot be disabled. The table below explains the behavior of the LED. -
Page 11: Pwr Led
Functional Details PWR LED LED turns on when external power is supplied. The USB-DIO96H incorporates an onboard voltage supervisory circuit that monitors the external power supply and disconnects power from the rest of the board components if the external power supply voltage is too high or too low. The... - Page 12 USB-DIO96H User's Guide Functional Details Screw terminal pinout Board label Signal name Board label Signal name P1A0 (FIRSTPORTA Bit 0) P3A0 (THIRDPORTA Bit 0) P1A1 (FIRSTPORTA Bit 1) P3A1 (THIRDPORTA Bit 1) P1A2 (FIRSTPORTA Bit 2) P3A2 (THIRDPORTA Bit 2)
-
Page 13: Digital I/O (Firstporta Bit 0 To Fourthportc Bit 7)
TTL level transitions from low to high (rising edge transitions), and can count frequencies up to 1 MHz. Power outputs The USB-DIO96H has three +5 V power output terminals. Each power output terminal is labeled . A total of 50 mA may be drawn from the three terminals. -
Page 14: Mechanical Drawings
USB-DIO96H User's Guide Functional Details Mechanical drawings Figure 7. Circuit board dimensions Figure 8. Enclosure dimensions... -
Page 15: Specifications
This specification covers revision 2 of the USB-DIO96H hardware, which uses a 5 V power supply. Revision 1 of the USB-DIO96H hardware was designed with a 9 V power supply and daisy chained hub. For revision 1 hardware specifications, refer to www.mccdaq.com/PDFs/specs/USB-DIO96H_R1-spec.pdf. -
Page 16: Power
USB-DIO96H User's Guide Specifications Power Table 2. Power specifications Parameter Conditions Specification USB +5 V input voltage range 4.75 V min to 5.25 V max USB +5 V supply current All modes of operation <100 mA External power input (Note 2) 5 VDC ±... -
Page 17: Environmental
USB-DIO96H User's Guide Specifications Environmental Table 4. Environmental specifications Parameter Specification Operating temperature range 0 °C to 60 °C Storage temperature range –40 °C to 85 °C Humidity 0% to 90% non-condensing USB specifications Table 5. USB specifications Parameter Specification USB "B"... -
Page 18: Screw Terminal Pinout
USB-DIO96H User's Guide Specifications Screw terminal pinout Table 9. Screw terminal pinout Board label Signal name Board label Signal name P1A0 (FIRSTPORTA Bit 0) P3A0 (THIRDPORTA Bit 0) P1A1 (FIRSTPORTA Bit 1) P3A1 (THIRDPORTA Bit 1) P1A2 (FIRSTPORTA Bit 2) -
Page 19: Ribbon Connectors
USB-DIO96H User's Guide Specifications Ribbon connectors Table 10. Ribbon connector specifications Parameter Specification Connectors P1-P4: 50-pin 0.1" IDC type box header Compatible cables C-50FF-x 50-pin ribbon cable Compatible accessory products SSR-PB24 (Note 3) SCB-50 CIO-MINI50 (2) CIO-TERM100 CIO-SPADE50 (2) CIO-ERB24... -
Page 20: P2 Pinout
USB-DIO96H User's Guide Specifications P2 pinout Table 12. P2 pinout Signal name Signal name SECONDPORTC Bit 7 SECONDPORTC Bit 6 SECONDPORTC Bit 5 SECONDPORTC Bit 4 SECONDPORTC Bit 3 SECONDPORTC Bit 2 SECONDPORTC Bit 1 SECONDPORTC Bit 0 SECONDPORTB Bit 7... -
Page 21: P3 Pinout
USB-DIO96H User's Guide Specifications P3 pinout Table 13. P3 pinout Signal name Signal name THIRDPORTC Bit 7 THIRDPORTC Bit 6 THIRDPORTC Bit 5 THIRDPORTC Bit 4 THIRDPORTC Bit 3 THIRDPORTC Bit 2 THIRDPORTC Bit 1 THIRDPORTC Bit 0 THIRDPORTB Bit 7... -
Page 22: P4 Pinout
USB-DIO96H User's Guide Specifications P4 pinout Table 14. P4 pinout Signal name Signal name FOURTHPORTC Bit 7 FOURTHPORTC Bit 6 FOURTHPORTC Bit 5 FOURTHPORTC Bit 4 FOURTHPORTC Bit 3 FOURTHPORTC Bit 2 FOURTHPORTC Bit 1 FOURTHPORTC Bit 0 FOURTHPORTB Bit 7... -
Page 23: Declaration Of Conformity
Date and Place of Issue: May 3, 2016, Norton, Massachusetts USA Test Report Number: EMI4813.07 Measurement Computing Corporation declares under sole responsibility that the product USB-DIO96H Complies with the essential requirements of the following applicable European Directives: Electromagnetic Compatibility (EMC) Directive 2004/108/EC... - Page 24 Measurement Computing Corporation NI Hungary Kft 10 Commerce Way H-4031 Debrecen, Hátar út 1/A, Hungary Norton, Massachusetts 02766 Phone: +36 (52) 515400 (508) 946-5100 Fax: +36 (52) 515414 Fax: (508) 946-9500 http://hungary.ni.com/debrecen E-mail: info@mccdaq.com www.mccdaq.com...
