USB-DIO96H User's Guide

P2 pinout

Pin Signal name
1 SECONDPORTC Bit 7
3 SECONDPORTC Bit 6
5 SECONDPORTC Bit 5
7 SECONDPORTC Bit 4
9 SECONDPORTC Bit 3
11 SECONDPORTC Bit 2
13 SECONDPORTC Bit 1
15 SECONDPORTC Bit 0
17 SECONDPORTB Bit 7
19 SECONDPORTB Bit 6
21 SECONDPORTB Bit 5
23 SECONDPORTB Bit 4
25 SECONDPORTB Bit 3
27 SECONDPORTB Bit 2
29 SECONDPORTB Bit 1
31 SECONDPORTB Bit 0
33 SECONDPORTA Bit 7
35 SECONDPORTA Bit 6
37 SECONDPORTA Bit 5
39 SECONDPORTA Bit 4
41 SECONDPORTA Bit 3
43 SECONDPORTA Bit 2
45 SECONDPORTA Bit 1
47 SECONDPORTA Bit 0
49 VDD
Table 12. P2 pinout
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
20
32
34
36
38
40
42
44
46
48
50
20
Signal name
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
