Power

Parameter
Supply current
Supply current (Note 11)
+5V user output voltage range (Note 12)
+5V user output current (Note 13)
ITEST output voltage range
ITEST output current (Note 14)
Note 11: This is the total quiescent current requirement for the USB-3102 which includes up to 10 mA for the status
LED. This does not include any potential loading of the digital I/O bits, +5V user terminal, ITEST, or the
VOUTx/IOUTx outputs.
Note 12: Output voltage range assumes USB power supply is within specified limits.
Note 13: This refers to the total amount of current that can be sourced from the +5V user terminal (pin 56) for general
use. This specification also includes any additional contribution due to DIO loading.
Note 14: This refers to the total maximum amount of current that can be sourced from the ITEST user terminal (pin 51).
The ITEST terminal pin should only be used for biasing individual IOUTx outputs in order to facilitate
functional testing. A load resistor of 100Ω should be placed in series between the ITEST pin and the IOUTx pin
for proper operation.

USB specifications

Parameter
USB device type
USB device compatibility
USB cable length
USB cable type

Environmental

Parameter
Operating temperature range
Storage temperature range
Humidity

Mechanical

Parameter
Dimensions (L × W × H)
Table 12. Power specifications
Conditions
USB enumeration
Quiescent current
Available at terminal block pin 56
Available at terminal block pin 56
Available at terminal block pin 51
Available at terminal block pin 51
Table 13. USB specifications
Specification
USB 2.0 (full-speed)
USB 1.1, 2.0
3 m (9.84 ft) max
A-B cable, UL type AWM 2527 or equivalent (min 24 AWG VBUS/GND,
min 28 AWG D+/D–)
Table 14. Environmental specifications
Specification
0 to 50 °C
–40 to 85 °C
0 to 90% non-condensing
Table 15. Mechanical specifications
Specification
127 × 89.9 × 35.6 mm (5.00 × 3.53 × 1.40 in.)
19
Specifications
Specification
< 100 mA
140 mA typ
4.5 V min, 5.25 V max
10 mA max
13V, ±1% typ
30mA max
