USB-DIO96H User's Guide

P3 pinout

Pin Signal name
1 THIRDPORTC Bit 7
3 THIRDPORTC Bit 6
5 THIRDPORTC Bit 5
7 THIRDPORTC Bit 4
9 THIRDPORTC Bit 3
11 THIRDPORTC Bit 2
13 THIRDPORTC Bit 1
15 THIRDPORTC Bit 0
17 THIRDPORTB Bit 7
19 THIRDPORTB Bit 6
21 THIRDPORTB Bit 5
23 THIRDPORTB Bit 4
25 THIRDPORTB Bit 3
27 THIRDPORTB Bit 2
29 THIRDPORTB Bit 1
31 THIRDPORTB Bit 0
33 THIRDPORTA Bit 7
35 THIRDPORTA Bit 6
37 THIRDPORTA Bit 5
39 THIRDPORTA Bit 4
41 THIRDPORTA Bit 3
43 THIRDPORTA Bit 2
45 THIRDPORTA Bit 1
47 THIRDPORTA Bit 0
49 VDD
Table 13. P3 pinout
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
20
32
34
36
38
40
42
44
46
48
50
21
Signal name
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
