USB-DIO96H User's Guide

P4 pinout

Pin Signal name
1 FOURTHPORTC Bit 7
3 FOURTHPORTC Bit 6
5 FOURTHPORTC Bit 5
7 FOURTHPORTC Bit 4
9 FOURTHPORTC Bit 3
11 FOURTHPORTC Bit 2
13 FOURTHPORTC Bit 1
15 FOURTHPORTC Bit 0
17 FOURTHPORTB Bit 7
19 FOURTHPORTB Bit 6
21 FOURTHPORTB Bit 5
23 FOURTHPORTB Bit 4
25 FOURTHPORTB Bit 3
27 FOURTHPORTB Bit 2
29 FOURTHPORTB Bit 1
31 FOURTHPORTB Bit 0
33 FOURTHPORTA Bit 7
35 FOURTHPORTA Bit 6
37 FOURTHPORTA Bit 5
39 FOURTHPORTA Bit 4
41 FOURTHPORTA Bit 3
43 FOURTHPORTA Bit 2
45 FOURTHPORTA Bit 1
47 FOURTHPORTA Bit 0
49 VDD
Table 14. P4 pinout
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
20
32
34
36
38
40
42
44
46
48
50
22
Signal name
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
