USB-DIO96H User's Guide

Ribbon connectors

Parameter
Connectors
Compatible cables
Compatible accessory products
(Note 3)
Note 3: P1-P4 connectors are located inside the enclosure. These connectors are available for applications where the
enclosure is not required.

P1 pinout

Pin Signal name
1 FIRSTPORTC Bit 7
3 FIRSTPORTC Bit 6
5 FIRSTPORTC Bit 5
7 FIRSTPORTC Bit 4
9 FIRSTPORTC Bit 3
11 FIRSTPORTC Bit 2
13 FIRSTPORTC Bit 1
15 FIRSTPORTC Bit 0
17 FIRSTPORTB Bit 7
19 FIRSTPORTB Bit 6
21 FIRSTPORTB Bit 5
23 FIRSTPORTB Bit 4
25 FIRSTPORTB Bit 3
27 FIRSTPORTB Bit 2
29 FIRSTPORTB Bit 1
31 FIRSTPORTB Bit 0
33 FIRSTPORTA Bit 7
35 FIRSTPORTA Bit 6
37 FIRSTPORTA Bit 5
39 FIRSTPORTA Bit 4
41 FIRSTPORTA Bit 3
43 FIRSTPORTA Bit 2
45 FIRSTPORTA Bit 1
47 FIRSTPORTA Bit 0
49 VDD
Table 10. Ribbon connector specifications
Specification
P1-P4: 50-pin 0.1" IDC type box header
C-50FF-x 50-pin ribbon cable
SSR-PB24
SCB-50
CIO-MINI50 (2)
CIO-TERM100
CIO-SPADE50 (2)
CIO-ERB24
CIO-SERB24/FD
CIO-ERB48
CIO-SERB48
SSR-RACK24
SSR-RACK48
Table 11. P1 pinout
19
Pin Signal name
2 GND
4 GND
6 GND
8 GND
10 GND
12 GND
14 GND
16 GND
18 GND
20 GND
22 GND
24 GND
26 GND
28 GND
20 GND
32 GND
34 GND
36 GND
38 GND
40 GND
42 GND
44 GND
46 GND
48 GND
50 GND
