Screw terminal pinout

Board label Signal name
A0 P1A0 (FIRSTPORTA Bit 0)
A1 P1A1 (FIRSTPORTA Bit 1)
A2 P1A2 (FIRSTPORTA Bit 2)
A3 P1A3 (FIRSTPORTA Bit 3)
A4 P1A4 (FIRSTPORTA Bit 4)
A5 P1A5 (FIRSTPORTA Bit 5)
A6 P1A6 (FIRSTPORTA Bit 6)
A7 P1A7 (FIRSTPORTA Bit 7)
B0 P1B0 (FIRSTPORTB Bit 0)
B1 P1B1 (FIRSTPORTB Bit 1)
B2 P1B2 (FIRSTPORTB Bit 2)
B3 P1B3 (FIRSTPORTB Bit 3)
Port 1
B4 P1B4 (FIRSTPORTB Bit 4)
B5 P1B5 (FIRSTPORTB Bit 5)
B6 P1B6 (FIRSTPORTB Bit 6)
B7 P1B7 (FIRSTPORTB Bit 7)
C0 P1C0 (FIRSTPORTC Bit 0)
C1 P1C1 (FIRSTPORTC Bit 1)
C2 P1C2 (FIRSTPORTC Bit 2)
C3 P1C3 (FIRSTPORTC Bit 3)
C4 P1C4 (FIRSTPORTC Bit 4)
C5 P1C5 (FIRSTPORTC Bit 5)
C6 P1C6 (FIRSTPORTC Bit 6)
C7 P1C7 (FIRSTPORTC Bit 7)
5V 5V
GND GND
A0 P2A0 (SECONDPORTA Bit 0)
A1 P2A1 (SECONDPORTA Bit 1)
A2 P2A2 (SECONDPORTA Bit 2)
A3 P2A3 (SECONDPORTA Bit 3)
A4 P2A4 (SECONDPORTA Bit 4)
A5 P2A5 (SECONDPORTA Bit 5)
A6 P2A6 (SECONDPORTA Bit 6)
A7 P2A7 (SECONDPORTA Bit 7)
B0 P2B0 (SECONDPORTB Bit 0)
B1 P2B1 (SECONDPORTB Bit 1)
B2 P2B2 (SECONDPORTB Bit 2)
B3 P2B3 (SECONDPORTB Bit 3)
Port 2
B4 P2B4 (SECONDPORTB Bit 4)
B5 P2B5 (SECONDPORTB Bit 5)
B6 P2B6 (SECONDPORTB Bit 6)
B7 P2B7 (SECONDPORTB Bit 7)
C0 P2C0 (SECONDPORTC Bit 0)
C1 P2C1 (SECONDPORTC Bit 1)
C2 P2C2 (SECONDPORTC Bit 2)
C3 P2C3 (SECONDPORTC Bit 3)
C4 P2C4 (SECONDPORTC Bit 4)
C5 P2C5 (SECONDPORTC Bit 5)
C6 P2C6 (SECONDPORTC Bit 6)
C7 P2C7 (SECONDPORTC Bit 7)
CTR CTR
GND GND
Table 9. Screw terminal pinout
Board label
A0
A1
A2
A3
A4
A5
A6
A7
B0
B1
B2
B3
Port 3
B4
B5
B6
B7
C0
C1
C2
C3
C4
C5
C6
C7
5V
GND
A0
A1
A2
A3
A4
A5
A6
A7
B0
B1
B2
B3
Port 4
B4
B5
B6
B7
C0
C1
C2
C3
C4
C5
C6
C7
5V
GND
18
Signal name
P3A0 (THIRDPORTA Bit 0)
P3A1 (THIRDPORTA Bit 1)
P3A2 (THIRDPORTA Bit 2)
P3A3 (THIRDPORTA Bit 3)
P3A4 (THIRDPORTA Bit 4)
P3A5 (THIRDPORTA Bit 5)
P3A6 (THIRDPORTA Bit 6)
P3A7 (THIRDPORTA Bit 7)
P3B0 (THIRDPORTB Bit 0)
P3B1 (THIRDPORTB Bit 1)
P3B2 (THIRDPORTB Bit 2)
P3B3 (THIRDPORTB Bit 3)
P3B4 (THIRDPORTB Bit 4)
P3B5 (THIRDPORTB Bit 5)
P3B6 (THIRDPORTB Bit 6)
P3B7 (THIRDPORTB Bit 7)
P3C0 (THIRDPORTC Bit 0)
P3C1 (THIRDPORTC Bit 1)
P3C2 (THIRDPORTC Bit 2)
P3C3 (THIRDPORTC Bit 3)
P3C4 (THIRDPORTC Bit 4)
P3C5 (THIRDPORTC Bit 5)
P3C6 (THIRDPORTC Bit 6)
P3C7 (THIRDPORTC Bit 7)
5V
GND
P4A0 (FOURTHPORTA Bit 0)
P4A1 (FOURTHPORTA Bit 1)
P4A2 (FOURTHPORTA Bit 2)
P4A3 (FOURTHPORTA Bit 3)
P4A4 (FOURTHPORTA Bit 4)
P4A5 (FOURTHPORTA Bit 5)
P4A6 (FOURTHPORTA Bit 6)
P4A7 (FOURTHPORTA Bit 7)
P4B0 (FOURTHPORTB Bit 0)
P4B1 (FOURTHPORTB Bit 1)
P4B2 (FOURTHPORTB Bit 2)
P4B3 (FOURTHPORTB Bit 3)
P4B4 (FOURTHPORTB Bit 4)
P4B5 (FOURTHPORTB Bit 5)
P4B6 (FOURTHPORTB Bit 6)
P4B7 (FOURTHPORTB Bit 7)
P4C0 (FOURTHPORTC Bit 0)
P4C1 (FOURTHPORTC Bit 1)
P4C2 (FOURTHPORTC Bit 2)
P4C3 (FOURTHPORTC Bit 3)
P4C4 (FOURTHPORTC Bit 4)
P4C5 (FOURTHPORTC Bit 5)
P4C6 (FOURTHPORTC Bit 6)
P4C7 (FOURTHPORTC Bit 7)
5V
GND
