USB-1408FS-Plus-OEM User's Guide

General

Parameter
Device type
Device compatibility

Environmental

Parameter
Operating temperature range
Storage temperature range
Humidity

Mechanical

Parameter
Dimensions (L × W × H)
USB cable length
User connection length

Header connector

Parameter
Connector type
Table 16. General specifications
Specification
USB 2.0 full speed
USB 1.1, USB 2.0
Table 17. Environmental specifications
Specification
0 °C to 70 °C
–40 °C to 70 °C
0% to 90% non-condensing
Table 18. Mechanical specifications
Specification
81.28 × 73.66 × 15.24 mm (3.20 × 2.9 × 0.6 in.)
3 m (9.84 ft) max
3 m (9.84 ft) max
Table 19. Header specifications
Specification
Two 20-pin, 0.1 in. pitch headers
24
Specifications
