Black Horse Model Midget Mustang Instruction Manual Book

All balsa ply wood construction covered with oracover
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Instruction Manual book
SPECIFICATION
Wingspan :
Length
Weight
Radio
Servo
Engine
1,450 mm
:
1,200mm
:
3.1 kg
:
05 channels.
:
07 servos.
:
61-75
2 stroke.
91
4 stroke.
57.09 in.
47.24in.
6.82 Lbs.
Made in Vietnam.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Midget Mustang and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Black Horse Model Midget Mustang

Summary of Contents for Black Horse Model Midget Mustang

  • Page 1 Instruction Manual book SPECIFICATION Wingspan : 1,450 mm 57.09 in. Length 1,200mm 47.24in. Weight 3.1 kg 6.82 Lbs. Radio 05 channels. Servo 07 servos. Engine 61-75 2 stroke. 4 stroke. Made in Vietnam.
  • Page 2 MIDGET-MUSTANG - Instruction Manual Item code: BH83 This instruction manual is designed to help you build a great flying aeroplane. Please read this manual thoroughly before starting assembly of your MIDGET-MUSTANG. Use the parts listing below to identify all parts. WARNING.

  • Page 3: Safety Precaution

    MIDGET-MUSTANG - INSTRUCTION MANUAL Item code: BH83. SAFETY PRECAUTION. + This is not a toy + Be sure that no other flyers are using your radio frequency. + Do not smoke near fuel + Store fuel in a cool, dry place, away from children and pets.
  • Page 4 MIDGET-MUSTANG - Instruction Manual Item code: BH83 C/A glue C/A glue Bottom side C/A glue Aileron Flap 2) Using a modeling knife, remove the cov- C/A glue ering at possition show below. Remove covering C/A glue Secure C/A glue 3) Using the thread as a guide and using masking tape, tape the servo lead to the end of the thread: carefully pull the thread out.
  • Page 5 MIDGET-MUSTANG - INSTRUCTION MANUAL Item code: BH83. 2x10mm. Secure 4) Drill 1,6mm pilot holes through the block of wood for each of the four mounting screws provided with the servo. Bottom side 5. Instal servo tray with aileron servo into the wing as same as picture below.

  • Page 6: Installing The Aileron Linkages

    MIDGET-MUSTANG - Instruction Manual Item code: BH83 A i l e r o n c o n t r o l horn. Repeat the procedure for the other wing half. 3.INSTALLING THE AILERON LINKAGES. Installing the aileron linkages as pictures below.

  • Page 7: Installing The Flap Servos

    MIDGET-MUSTANG - INSTRUCTION MANUAL Item code: BH83. 2x10mm. C/A glue C/A glue II. FLAP. 1.INSTALLING THE FLAP SERVOS. 2.INSTALLING THE FLAP CONTROL HORN. Servo tray 3mm x 40mm. M3 lock nut. Nilon control clasp Thread E l e c t r i c wire...
  • Page 8 MIDGET-MUSTANG - Instruction Manual Item code: BH83 3. INSTALLING THE FLAP LINKAGES. Installing the aileron linkages as pictures below. M2 lock nut 80mm C/A glue. Aileron Flap Flap control horn. Repeat the procedure for the other wing half.
  • Page 9 MIDGET-MUSTANG - INSTRUCTION MANUAL Item code: BH83. MAIN GEAR INSTALATION. PARTS REQUIRED Secure Mark point...
  • Page 10 MIDGET-MUSTANG - Instruction Manual Item code: BH83 Secure Secure Repeat the procedure for the other wing half.

  • Page 11: Installing The Engine Mount

    MIDGET-MUSTANG - INSTRUCTION MANUAL Item code: BH83. INSTALLING THE ENGINE MOUNT. See pictures below: 4x 30mm 4x 30mm FUEL TANK. INSTALLING THE STOPPER ASSEMBLY 1) The stopper has been pre-assembled at the factory. 2) Using a modeling knife, cut one length of silicon fuel line (the length of silicon fuel line is calculated by how the weighted clunk should rest about 8mm away from the rear of the tank...
  • Page 12 MIDGET-MUSTANG - Instruction Manual Item code: BH83 Secure 8) Feed three lines through the fuel tank compartment and through the pre-drilled hole in the firewall. Pull the lines out from behind the engine, while guiding the fuel tank into place. Push the fuel tank as far forward as possible, the front of the tank should just about touch the back of the firewall.

  • Page 13: Installing The Engine

    MIDGET-MUSTANG - INSTRUCTION MANUAL Item code: BH83. Fuel tank Mark point Drill 2mm diameter. INSTALLING THE ENGINE. Locate the long piece of wire used for the throttle pushrod. One end of the wire has been pre-bend in to a “Z” bend at the factory. This “Z”...
  • Page 14 MIDGET-MUSTANG - Instruction Manual Item code: BH83 Bottom side 1. Slide the fiberglass cowl over the en- gine and line up the back edge of the cowl with the marks you made on the fuselage. 2. While keeping the back edge of the cowl flush with the marks, align the front of the cowl with the crankshaft of the engine.

  • Page 15: Installing The Spinner

    MIDGET-MUSTANG - INSTRUCTION MANUAL Item code: BH83. Trim and cut INSTALLING THE SPINNER. Install the spinner backplate, propeller and spinner cone. The spinner cone is held in place using two 3mm x 12mm wood screws. 3 x 12mm Left side Right side Left side Bottom side...

  • Page 16: Horizontal Stabilizer

    MIDGET-MUSTANG - Instruction Manual Item code: BH83 Connector. Servo arm. After installing the adjustable metal con- nector apply a small drop of thin C/A to the bottom nut. This will prevent the con- nector from loosening during flight. ELEVATOR INSTALLATION. Throttle servo SERVO INSTALLATION.
  • Page 17 MIDGET-MUSTANG - INSTRUCTION MANUAL Item code: BH83. C/A glue C/A glue C/A glue C/A glue C/A glue C/A glue C/A glue 1. Draw a center line onto the horizontal stabilizer. Then slide the horizontal into the fuselage.
  • Page 18 MIDGET-MUSTANG - Instruction Manual Item code: BH83 4. Remove the stabilizer. Using the lines you just drew as a guide, carefully remove the covering from between them using a modeling knife. When cutting through the covering to re- move it, cut with only enough pressure to Center line only cut through the covering it’s self.
  • Page 19 MIDGET-MUSTANG - INSTRUCTION MANUAL Item code: BH83. 5. When you are sure that everything is ELEVATOR CONTROL HORN PUSHROD INSTALLATION. aligned correctly, mix up a generous amount of 30 minute epoxy. Apply a thin layer to the top and bottom of the stabilizer mounting area Elevator control horn install as same as the and to the stabilizer mounting platform sides way of aileron control horn.

  • Page 20: Elevator Pushrod Installation

    MIDGET-MUSTANG - Instruction Manual Item code: BH83 E l e v a t o r E l e v a t o r pushrod pushrod Elevator control horn. ELEVATOR PUSHROD INSTALLATION. Elevator pushrod install as same as the way of aileron pushrod. M2 lock nut.

  • Page 21: Vertical Installation

    MIDGET-MUSTANG - INSTRUCTION MANUAL Item code: BH83. C/A glue Secure VERTICAL INSTALLATION. Rudder servo install as same as method of elevator servo. See picture below: 1) Using a modeling knife, remove the covering from the top of the fuselage and the covering from over the precut hinge slot cut into the lower rear portion of the fuselage This slot accepts the lower vertical.
  • Page 22 MIDGET-MUSTANG - Instruction Manual Item code: BH83 2. Put the rudder into the fuselage as same as picture below. Epoxy glue 3. Mark the shape of the vertical on the left and right side of the rudder on to the hori- zontal stabilizer using a felt-tip pen.
  • Page 23 MIDGET-MUSTANG - INSTRUCTION MANUAL Item code: BH83. 5.) When you are sure that everything is a aligned correctly, mix up a generous amount of 30 minute epoxy. Apply a thin layer to the slot in the mounting platform and to the verti- C/A glue.

  • Page 24: Rudder Control Horn Installa- Tion

    MIDGET-MUSTANG - Instruction Manual Item code: BH83 RUDDER CONTROL HORN INSTALLA- TION. Rudder control horn install as same as the way of aileron control horn. Please see pic- tures below. 3mm x 40mm. M3 lock nut. Nilon control clasp Control horn of Rudder. RUDDER PUSHROD INSTALLATION.
  • Page 25 MIDGET-MUSTANG - INSTRUCTION MANUAL Item code: BH83. Elevator Elevator pushrod pushrod C/A glue. Rudder pushrod C/A glue. C/A glue. Cut. C/A glue.

  • Page 26: Mounting The Tail Wheel Bracket

    MIDGET-MUSTANG - Instruction Manual Item code: BH83 C/A glue. Secure MOUNTING THE TAIL WHEEL BRACKET. 3x12mm 1. Set the tail wheel assembly in place on the plywood plate. The pivot point of the tail wheel wire should be even with the rud- der hinge line and the tail wheel bracket should be centered on the plywood plate.

  • Page 27: Installing The Receiver And Battery

    MIDGET-MUSTANG - INSTRUCTION MANUAL Item code: BH83. Tie wrap. switch Tie wrap for Receiverr. INSTALLING THE RECEIVER AND BATTERY. 1. Plug the servo leads and the switch lead into the receiver. You may want to plug an aileron extension into the receiver to make plugging in the aileron servo lead easier when you are installing the wing .
  • Page 28 MIDGET-MUSTANG - Instruction Manual Item code: BH83 WING ATTACHMENT. See picture wing attach to fuselage. Wing bolt. Drill a hole 3mm diameter Installing the fuselage hatch as same as pic- ture below. 4 x 30mm Left side Secure Secure Drill a hole 3mm diameter...
  • Page 29 MIDGET-MUSTANG - INSTRUCTION MANUAL Item code: BH83. Top side Secure BALANCING. 1) It is critical that your airplane be bal- anced correctly. Improper balance will cause your plane to lose control and crash. THE CENTER OF GRAVITY IS LOCATED 80MM BACK FROM THE LEADING EDGE OF THE WING.

  • Page 30: Pre-Flight Check

    MIDGET-MUSTANG - Instruction Manual Item code: BH83 PRE-FLIGHT CHECK. 1) Completely charge your transmitter and receiver batteries before your first day of fly- ing. 2) Check every bolt and every glue joint in your plane to ensure that everything is tight and well bonded.
