Instruction Manual book
SPECIFICATION
Wingspan :
Length
Weight
Radio
Servo
Motor
Battery
Speed control: 60A.
Propeller: 10 x 10.
1,000 mm
:
860 mm
:
1,4 kg
:
04 channels.
:
04 mini servos.
:
KMS 2820/05.
:
3 Cells-Li-Poly-1 1.1V 2.200 mAh.
39.37 in.
33.86 in.
3.08 Lbs.
Made in Vietnam.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIDGET MUSTANG-EP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Black Horse Model MIDGET MUSTANG-EP

Summary of Contents for Black Horse Model MIDGET MUSTANG-EP

  • Page 1 Instruction Manual book SPECIFICATION Wingspan : 1,000 mm 39.37 in. Length 860 mm 33.86 in. Weight 1,4 kg 3.08 Lbs. Radio 04 channels. Servo 04 mini servos. Motor KMS 2820/05. Battery 3 Cells-Li-Poly-1 1.1V 2.200 mAh. Speed control: 60A. Propeller: 10 x 10. Made in Vietnam.

  • Page 2: Parts List

    MIDGET MUSTANG-EP - Instruction Manual Item code: BH81 This instruction manual is designed to help you build a great flying aeroplane. Please read this manual thoroughly before starting assembly of your MIDGET MUSTANG - EP. Use the parts listing below to identify all parts.

  • Page 3: Safety Precaution

    MIDGET MUSTANG-EP - INSTRUCTION MANUAL Item code: BH81 SAFETY PRECAUTION. + This is not a toy + Be sure that no other flyers are using your radio frequency. The glow plug clip must be securely attached to the glow plug.
  • Page 4 MIDGET MUSTANG-EP - Instruction Manual Item code: BH81 C/A glue Bottom side Bottom side 2) Using a modeling knife, remove the cov- ering at possition show below. Remove covering C/A glue C/A glue Secure 3) Using the thread as a guide and using masking tape, tape the servo lead to the end of the thread: carefully pull the thread out.
  • Page 5 MIDGET MUSTANG-EP - INSTRUCTION MANUAL Item code: BH81 Straitgh line. 2) Insert aileron control horn to the aileron. 2x10mm. 3) Drill two 2mm holes through the aileron using the control horn as a guide and screw the control horn in place.
  • Page 6 MIDGET MUSTANG-EP - Instruction Manual Item code: BH81 INSTALLING THE AILERON MAIN GEAR INSTALATION. LINKAGES. PARTS REQUIRED 3 x15 mm 4 x 35 mm Aileron pushrod. Aileron pushrod. Remove covering Bottom side Top side Repeat the procedure for the other wing...
  • Page 7 MIDGET MUSTANG-EP - INSTRUCTION MANUAL Item code: BH81 C/A glue Secure Secure Drill 4mm hole Repeat the procedure for the other wing half.
  • Page 8 MIDGET MUSTANG-EP - Instruction Manual Item code: BH81 INSTALLING ELECTRIC MOTOR. See pictures below: Push C/A glue. 3 x 15mm Epoxy glue. Motor mount wood Epoxy glue. C/A glue.
  • Page 9 MIDGET MUSTANG-EP - INSTRUCTION MANUAL Item code: BH81 Left side COWLING. 1. Slide the fiberglass cowl over the en- gine and line up the back edge of the cowl with the marks you made on the fuselage. Rotor shaft 2. While keeping the back edge of the...
  • Page 10 MIDGET MUSTANG-EP - Instruction Manual Item code: BH81 3 x 12mm Right side Machine screw. Secure. ELEVATOR INSTALLATION. Left side SERVO INSTALLATION. 1. Install the rubber grommets and brass collets into the elevator servo. Test fit the servo into the servo tray.

  • Page 11: Horizontal Stabilizer

    MIDGET MUSTANG-EP - INSTRUCTION MANUAL Item code: BH81 C/A glue HORIZONTAL STABILIZER. See pictures below: C/A glue Check to mark sure the wing and stabi- lizer are paralell. If they are not, lightly sand the opening in the fuselage for the stabilizer C/A glue until the stabilizer is paralell to the wing.
  • Page 12 MIDGET MUSTANG-EP - Instruction Manual Item code: BH81 Remove covering 5. When you are sure that everything is aligned correctly, mix up a generous amount of 30 minute epoxy. Apply a thin layer to the top and bottom of the stabilizer mounting area and to the stabilizer mounting platform sides in the fuselage.

  • Page 13: Elevator Control Horn Installa- Tion

    MIDGET MUSTANG-EP - INSTRUCTION MANUAL Item code: BH81 C/A glue Drill a hole 2mm diameter. C/A glue ELEVATOR CONTROL HORN INSTALLA- TION. Elevator control horn install as same as the way of aileron control horn. Please see pic- tures below.
  • Page 14 MIDGET MUSTANG-EP - Instruction Manual Item code: BH81 Secure Secure E l e v a t o r E l e v a t o r pushrod pushrod Bottom side Top side Secure C/A glue.

  • Page 15: Vertical Installation

    MIDGET MUSTANG-EP - INSTRUCTION MANUAL Item code: BH81 C/A glue Elevator servo. C/A glue VERTICAL INSTALLATION. Rudder servo install as same as method of elevator servo. See picture below: C/A glue C/A glue 1. Using a modeling knife cut away the covering from the end of fuselage for the rud- der hinge.
  • Page 16 MIDGET MUSTANG-EP - Instruction Manual Item code: BH81 Also carefully remove the covering from the horizontal fin as below the lines which you drew as same picture below. Remove covering Hinge slot. 2. Put the rudder into the fuselage as same as picture below.

  • Page 17: Rudder Control Horn Installa- Tion

    MIDGET MUSTANG-EP - INSTRUCTION MANUAL Item code: BH81 RUDDER CONTROL HORN INSTALLA- Epoxy glue TION. Rudder control horn install as same as the way of aileron control horn. Please see pic- tures below. Epoxy glue C/A glue Mark point C/A glue...
  • Page 18 MIDGET MUSTANG-EP - Instruction Manual Item code: BH81 C/A glue Elevator Elevator pushrod. pushrod. Secure Rudder pushrod. Elevator RUDDER PUSHROD INSTALLATION. pushrod. Rudder pushrod install as same as the way of aileron pushrod. M2 lock nut. Rudder pushrod. Rudder pushrod.

  • Page 19: Wing Attachment

    MIDGET MUSTANG-EP - INSTRUCTION MANUAL Item code: BH81 2. Wrap the receiver and battery pack in the protective foam to protect them from vi- bration. Use a rubber band or masking tape to hold the foam in place. 3. Position the battery pack and receiver behind the fuel tank.
  • Page 20 MIDGET MUSTANG-EP - Instruction Manual Item code: BH81 Secure. WING ATTACHMENT. See picture wing attach to fuselage. Wing bolt. Installing the fuselage hatch as same as pic- ture below. Wing bolt.

  • Page 21: Control Throws

    MIDGET MUSTANG-EP - INSTRUCTION MANUAL Item code: BH81 BALANCING. CONTROL THROWS. 1) It is critical that your airplane be bal- 1) We highly recommend setting up a anced correctly. Improper balance will cause plane using the control throws listed. your plane to lose control and crash.
